The Screw Air Compressor C-series is a line of heavy-duty Diesel-Driven Air Compressor designed for mobile air supply needs in challenging environments. Engineered with professional screw airends and high-performance engines, these compressors deliver consistent, efficient airflow for applications like geological drilling, open-pit mining, and high-altitude construction. Unlike stationary models, the Mobile Air Compressor units prioritize portability and adaptability, featuring optional packages for low temperatures and high altitudes to ensure reliable operation where other equipment fails. As a cornerstone of industrial and construction projects, this series redefines what it means to be an Extreme Environment Air Compressor.
The C-series stands out as an Extreme Environment Air Compressor with optional low-temperature and plateau packages. It operates seamlessly in temperatures below -10℃ and altitudes above 3,000 meters, solving the common problem of equipment shutdown in harsh conditions. Whether deployed in frozen northern worksites or mountainous infrastructure projects, this compressor maintains peak performance.
Equipped with high-performance engines and professional screw airends, the High-Efficiency Air Compressor delivers 15% better compression efficiency than standard models. These core components are built for long-term continuous operation, reducing exhaust loss and ensuring stable airflow even during extended shifts. Contractors can rely on this consistency for time-sensitive projects like drilling and mining.
Each Intelligent Air Compressor features an integrated controller that displays real-time operating parameters—including temperature, pressure, and fuel levels—and triggers automatic warnings for abnormalities. This eliminates the need for constant manual monitoring, reducing labor costs and making the unit easy to operate for novices. The intuitive interface simplifies adjustments, allowing users to fine-tune airflow to match project needs.
The Mobile Air Compressor is tailored for mobile air supply scenarios, with a design that adapts to geological drilling, open-pit mining, and other on-the-go applications. Matching packages for extreme conditions mean no additional modifications are needed—simply select the appropriate kit for your environment and deploy immediately. This versatility makes the C-series a valuable asset for contractors working across diverse regions.
Air Compressor Model | C1100 | C1100-IV | Y1100 | C1300 | C1400 | C1588 | C1688 | V1588 | V1525H | ||||||||||||||||||
Air Compressor | Displacement(m3/min) | 30-26 | 31-27.5 | 32-25 | 36.8-32 | 40-35 | 45-36.8 | 48.5-45 | 45-40 | 43.2-38-35 | |||||||||||||||||
Operating Pressure Range(bar) | 15-25 | 15-25 | 15-30 | 18-34 | 18-35 | 15-35 | 15-20 | 25-35 | 25-35-40 | ||||||||||||||||||
Lubrication oil capacity(L) | 110 | 120 | 140 | ||||||||||||||||||||||||
Fuel tank Capacity(L) | 500 | 400 | 700 | 940 | 1100 | ||||||||||||||||||||||
Engine | Manufacturer | NYSE：CMI | NYSE：CMI | Yuchai | NYSE：CMI | NYSE：CMI | NYSE：CMI | Volvo | |||||||||||||||||||
Model | L9 PLUS T3 | L9CS4 430C | YC6MK400 | QSZ13- | QSM15 | QSM15 C77 | TAD1643VE | ||||||||||||||||||||
Rated Power(kW) | 294 | 316 | 295 | 410 | 563 | 563 | 565 | ||||||||||||||||||||
Operating speed(rpm) | 1850 | 1900/1650 | 1900/1650 | 1900/ | 1900/ | 1900/ | 1750/ | 1850/ | 1900/1700/ | ||||||||||||||||||
Unloading Speed(rpm) | 1400 | 1400 | 1400 | 1400 | 1350 | 1350 | 1350 | ||||||||||||||||||||
Total Weight | Skid-Mounted(kg) | 4000 | 4500 | 5000 | 6000 | 6200 | 6500 | 6800 | |||||||||||||||||||
Trailer-Mounted(kg) | 4750 | 5300 | 5800 | 6800 | 7000 | 7500 | 7800 | ||||||||||||||||||||
Overall Dimentions(mm) | Skid-Mounted(mm) | 3200x1860x2250 | 3550x1860x2150 | 3850x1800x2250 | 4150x2000x2350 | 4850x2150x2450 | |||||||||||||||||||||
Trailer-Mounted(mm) | 3750x1860x2550 | 3750x1860x2550 | 4150x1800x2450 | 4450x2000x2550 | 5400x2150x2600 | ||||||||||||||||||||||
Optional-Configuration | Low-Temperature Working Condition Kit | Optional | Optional | ||||||||||||||||||||||||
Plateau Working Condition Kit | Optional | ||||||||||||||||||||||||||
As a specialized Geological Drilling Air Compressor, the C-series provides the high-pressure airflow needed for reverse circulation drilling and rock fragmentation. Its mobile design allows it to move alongside drilling rigs, ensuring a continuous air supply for efficient operation in remote exploration sites.
Mining sites rely on the Mining Air Compressor to power pneumatic tools, ventilation systems, and material handling equipment. The C-series’ durable construction and high airflow output make it ideal for the dusty, high-demand environment of open-pit mines, where reliability is non-negotiable.
In cold regions, the low-temperature package allows the Extreme Environment Air Compressor to start and operate reliably in temperatures below -10℃. This makes it essential for winter construction projects, such as pipeline installation and frozen ground drilling.
Beyond drilling and mining, the Mobile Air Compressor provides on-demand air supply for industrial maintenance, emergency repairs, and temporary worksites. Its trailer-mounted option allows easy transport between locations, making it a flexible solution for businesses with dynamic needs.
With the optional plateau package, the Plateau-Ready Air Compressor operates efficiently at altitudes above 3,000 meters. Without the package, it performs best at elevations below 1,500 meters.
The low-temperature package enables reliable operation in temperatures below -10℃. For even colder conditions, contact the manufacturer for custom modifications.
Yes, the High-Efficiency Air Compressor features an adjustable operating pressure range, allowing it to adapt to both high-pressure (drilling) and medium-pressure (pneumatic tools) applications.
